BL590 Universal Isolated Signal Conditioners | Input up to ±1000 mV | Passive current output | Isolation up to 500 V

Skip image gallery
Product number: BL590
Description Technical details Downloads Use cases Blog posts

Description

BL590 Universal Isolated Signal Conditioners | Input up to ±1000 mV | Passive current output | Isolation up to 500 V

Designed to measure currents and voltages with up to 500 V

  • Calibrated range selection
  • 10 selectable input ranges and unipolar as well as bipolar output signals
  • Universal power supply for 24 V DC supply or 100 … 230 V AC mains supply
  • Only 17.5 mm wide modular housing with comprehensive functionality
  • Passive output for direct connection to a supplying PLC
  • Monitor output for non-disruptive measurement of the output current by connecting a multimeter or permanently connecting an isolated display unit
  • Galvanic 3-port isolation for undistorted transmission of the measuring signals or damages
  • Highest reliability
  • Optimum price/perfomance ratio
  • 3 year warranty

The Transducer BL590 is designed to measure currents and voltages in applications with up to 500 V. Short circuit recognition, monitoring and control of motors, recognition of DC-link voltage or battery current/voltage are some use case examples. The input is galvanically isolated from output and auxiliary power. The housing can be quickly snapped on a DIN-Rail. The product comes with 10 selectable input ranges and unipolar as well as bipolar output signals. The device automatically calibrates itself after switching input or output ranges.

We look forward to hearing from you!
Contact Us

Technical details

Product Category: Isolated Signal Conditioner
Device Type: Universal Isolated Signal Conditioners
Input: (±)500 mV ... (±)200 V, > (±)200 V
Output: 0 … 10 V, 0 … 20 mA, 4 … 20 mA, ±10 V, ±20 mA
Working Voltage, Min.: 50 V, 300 V
Fault Class: < 0.5 %
Housing: 17.5 … 67.5 mm Modular housing
Cutoff Frequency: 5 kHz, < 1 kHz
Power Supply: 24 V DC, 110 / 115 V AC, 220 / 230 V AC, Broad-range power supply
Approvals: CSA, UL
Product Line: BasicLine

Downloads

Manuals

[16991] User Manual (DE, EN, FR)
BL590/591
Version 01

Brochures

[14160] Brochure
Product Overview Interface Technology
[18222] Brochure
RELIABLE EQUIPMENT FOR HIGH VOLTAGE TEST & MEASUREMENT
APPLICATIONS IN E-MOBILITY

Data Sheets

[16997] Data Sheet
BL590/591
Product Description | Specifications | Product Range

Certificates

[14130] EU Declaration of Conformity (DE, EN, FR)
No. EU210803A | 2021-08-03
BL513, BL570, BL590, BL591
[11729] Certificate of Compliance (UL)
High-Voltage isolation amplifiers
P2900*P2/00..., P2900*P2/01..., BL590, BL591
ZT231124E
